Trend IP Driver
Specification
- Shared Point Pack Resource
- Requires 1xVCNC per Trend LAN connection
- Additional VCNC licenses easily added to the Point Pack
- Auto discovery of VCNC connection
- Auto discovery of Trend Outstations (Support for IQ3 / IQ4 / Legacy IQ2 & IQ1)
- Auto discovery of Points
- Sensors / Inputs / Drivers / Knobs / Switches / Loops
- Manual programming (Logic / Function blocks etc)
- Programming Config Mode for legacy controllers
- Full Support for Time Zones (Import and Export)
- License packs to suit every project
N4.10 / N4.11 / N4.12
Each licence pack includes POINTS and 1x VCNC Connection. Addition license features include Time Schedules & Additional VCNCs. Requires available Global Capacity License to be available Product includes SMA (Current Release + Next Release of N4 Support -e.g. N4.12 & N4.13)
Niagara 4.10 and above.
Available Tridium Global Capacity Point Licences (1x Tridium Point License per Trend Point).
Basic knowledge and understanding of the Trend system.
| Versions | Price |
|---|---|
| Trend IP Driver -100 | $424.84 |
| Trend IP Driver -250 | $508.95 |
| Trend IP Driver -500 | $649.15 |
| Trend IP Driver -1000 | $929.54 |
| Trend IP Driver -2000 | $1,490.32 |
| Trend IP Driver -5000 | $3,172.67 |
| Trend IP Driver -7500 | $4,574.63 |
| Trend IP Driver -10000 | $5,976.59 |
Question: What Trend Controllers are supported?
Answer: This driver is compatible with the full range of Trend controllers. IQ4 / IQ3 / IQ2 & IQ1 ranges, including IQeco and IQL units. The driver connect to the Trend system over IP to an available VNCNC (1x VCNC per Trend LAN is required).
Question: Are Time Zones supported?
Answer: Yes. The time zone feature is very similar to that of the BACnet driver. A schedule import (read only) and schedule export (to link to a Tridium schedule will be presented). Note, Time Zones are an additional license feature to a standard point pack.
Question: Is the license dependent on Tridiums SMA being active?
Answer: No!
The license is perpetual from purchase.
Note, the product has an inbuilt software maintenance agreement (SMA).  The product will be licensed to support the current release of N4 and the next release of N4.  For example, a new purchase will support N4.12 & N4.13 only. The license will also cover previous version of N4, for example N4.10.
Any future upgrades (for example, to N4.14) will require an SMA upgrade to be purchased.
All Tyrrell developed drivers include a software maintenance feature. Every new purchase of the driver will support the current release of Niagara 4 and the next release of Niagara 4, any subsequent upgrades will require a software maintenance license to be purchased.
As an example the current release of Niagara 4 is N4.12, a new driver purchase will cover you for N4.12 and a future upgrade to N4.13. Any further upgrades, for example to N4.14 or above, will require a software maintenance license to be updated. The software maintenance license would then cover you for the now current release of Niagara 4 (as an example N4.14) and next release of Niagara 4 (as an example N4.15). You can upgrade from any previous release with a single software maintenance purchase. Tridium SMA license features may also be required.
Any questions or queries in relation to this item should be sent to sales@tyrrellproducts.com
